BishopSound BDP12 12″ 400w RMS 8 Ohm LF Woofer

£90.00

Out of Stock - Call 02072494814 for Availability

Description

BDP12 – 12″ Speaker 400w RMS Full Range Cast Alloy LF Driver

Key Features

  • Faston Terminals, 80 Oz Magnet, 3″ Voice Coil – 8 ohm
  • Cast Aluminium Basket for rigidity and longer life
  • Frequency Range 45Hz to 5 kHz
  • Sensitivity@1W/1m 95 dB
  • This cast alloy 12″ LF Speaker driver is critical in covering those midrange frequencies. Our 12″ PA speakers can be used in a range of cabinets and applications such as wedge monitors. This driver operates well between Frequency Ranges 45Hz to 5 kHz. Very similar to the PD123ER and RCF LF12G301.

    • 400w RMS
    • 800w Program Power
    • 1600w Peak Power

    Bishopsound woofers are high-quality PA speakers using a cast aluminium chassis. Made from professional-grade materials the Premium Series features Kapton coils, ferrite magnets, paper cones with rolled cloth edges and push terminals.

    These 12″ speakers are ideal for use in vocal PA, keyboards, club systems and stage monitors.

    Product Weight 6kg
    Product Depth 14.2cm
    Product Height 31.2cm
    Product Width 31.2cm
    RMS Power: 400w
    Magnet Type: Ferrite
    Nominal Overall Diameter: 312mm
    Total Q Factor: Qts 0.48
    Mechanical Moving Mass: Mms 72.34g
    Mechanical Compliance: Cms 92.1 um/N
    Force Factor: BL 18.225 Wb/m
    Equivalent Acoustic Volume: Vas 34.9 It.
    EBP: 140
    Xlim: 18mm
    Voice Coil Winding: Copper
    Voice Coil Former: Kapton
    Basket: Diecast Aluminium
    Nominal Impedance: 8 Ohm
    Surround: Treated Cloth
    Nominal Voice Coil Diameter: 75mm
    Magnet Weight: 80oz
    Frequency Range: 45Hz to 5 kHz
    Flux Density: 1.2 T Sensitivity@1W/1m 95 d B
    Resonance Frequency: Fs 45.0 Hz
    Mechanical Q Factor: Qms 10.91
    Electrical Q Factor: Qes 0.52
    Cut Out Diameter 279mm

Additional information

Weight 6 kg
Dimensions 312 × 312 × 142 mm
Ohms

4 Ohm, 8 Ohm
