Description
The P420 is a multi-pattern large diaphragm true condenser microphone for demanding project studio recording applications. Offering high sensitivity and 155dB maximum SPL, the P420 delivers a warm, transparent sound quality perfectly suited for ensemble recording, grand piano, woodwind and brass instruments, as well as drums and percussion. With three selectable polar patterns – cardioid, omnidirectional or figure 8 – it is an ideal tool for stereo miking techniques and ambient recording.
General Specifications
Audio frequency bandwidth – 20 – 20000 Hz
Equivalent noise level – 15 dB-A
Sensitivity – 28 mV/Pa
Signal to Noise – 79 dB-A
Preattenuation Pad – -20 dB
Bass cut filter – 300 Hz – 12 dB/octave
Electrical impedance – <= 200 Ohms
Recommended load impedance – >= 1000 Ohms
Polar Patterns – Cardioid, Omnidirectional, and Figure of eight
Dimensions
Length – 165 mm
Diameter – 54 mm
Net Weight – 530 g
Audio Output
Type – Balanced XLR
Gender – Male
Contacts – 3-pin
Powering Interface
Voltage – 44 to 52 V
Current – <= 3 mA
Application
Project Studio – Yes
Instrument
Piano / Strings – Yes
Horns / Woodwinds – Yes
Drums / Percussion – Yes
